2005 CRN 128 BUNKER

• Make: CRN

• Model: 128

• Condition: Used

• Category: Power

• Construction: Composite

• Boat Hull ID: MIC123456789

• Has Hull ID: Yes

• Length: 40.23 m / 132 ft

• Length Overall: 40.23 m / 132 ft

• Beam: 25.25 ft ft

• Make: MTU

• Model: 12V 4000 M90

• Drive Type: V

• Fuel: diesel

• Engine Power: 2735|horsepower

• Type: Inboard

• Engine Hours: 5600

• Engine Location: Port

• Model: 12V 4000 M90

• Drive Type: V

• Fuel: diesel

• Engine Power: 2735|horsepower

• Type: Inboard

• Engine Hours: 5600

• Engine Location: Starboard

• Total Engine Power: 5470|horsepower

• Fuel Tanks: 1

• Fuel Tank Capacity: 28000|liter

• Water Tanks: 1

• Water Tank Capacity: 5000|liter

• Holding Tank Count: 1

• Holding Tank Capacity: 2410|liter

Type:                                      Motor Yacht

Hull No:                                  128/02

Builder:                                  CRN (Custom Line)

Naval Architect:                     CRN

Exterior Design:                    Zuccon International Project

Year built:                              2005

Year refits:                             2012 / 2015 / 2017

Construction:                         GRP

Classification:                         RINA 100-A-1.1 “Y” In compliance with MCA

Flag:                                        Cayman Islands

Crew:                                      Up to 8

Engines:                                 2 x MTU 12v4000 M90 2.735CV

Gross Tonnage:                      328

Displacement:                        238.6 t (Full Load)

SPEED, RANGE & CONSUMPTION

Maximum speed:                  22 kn

Cruising speed:                     17 kn

Range:                                   Approximately 700nm @ 17 kn, 1,500 nm @ 12 kn

Consumption:                        700l/h @ 17 kn - 350l/h @ 12.5 kn

CAPACITIES

Fuel:                                        28,000 liters/ 7,396 US gallons

Fresh water:                            5,000 liters/ 1,320 US gallons

Gray/sewage water:                2,410 liters/ 636 US gallons

ACCOMMODATIONS

Accommodation guests:        12 Guests in 5 Cabins

Crew Accommodation:          8 Crew in 4 Cabins

Owner Suite:

The owner suite is fitted with a double King bed located centrally in the room with comfortable seating around and automated AV system. An on-suite full bathroom with his and hers sink located forward and entrance to the suite is via the owner’s walking closet.

Guest staterooms:

Four staterooms on the lower deck. The two aft VIP rooms are fitted with double beds and the two forward twin rooms are fitted with twin singles with option of a third bed as a Pullman. All rooms are fitted with on-suites full bathrooms.

• All linens and towels are from the brands Matarranz.

• All interior furniture is from the brand Roche Bobois.

MECHANICAL EQUIPMENT

Engines:                                2 x MTU 12v4000 M90 2,040 KW

Engine hours:                        Port 5562 H. / Stbd 5570 (May 2023)

Engine Overhaul                    Port  2019     / Stbd 2018

Propellers:                             5 blades

Gearboxes:                             2 x MTU ZF 4650 a

Bow-thruster:                        American bow thruster, hydraulic from main engine bow/stern thrust fuel centrifuge separator: Gianneschi & Ramacciotti Jet 518BTE 230-400 v 3F

Stabilizers:                             Trac 2-fin, Zero speed stabilizer

Generators:                            Kohler 100 EFOZ 50Hz

Generator hours:                   Port 12356 / 13484 Stbd  (April 2023)

Power Converter:                  ASEA shore power converter 380-400

Watermakers:                        2 x Idromar MC3J 380 50Hz, 9000l/day

Hot water system:                 2 x Gianneschi & Ramcciotti boiler 300

Toilet system:                        Vacuum pumps Jet 25MBA

Sewage treatment:                Hamann H-L CONT

Air conditioning:                   Condaria 90002 WMC/011 380v R2

Air compressor:                     Ficic 250cfm (shell plate seals main compressor)

GALEY & LAUNDRY APPLIANCES

Galey:

2 x Angelo Po, refrigerator

2 x Angelo Po, freezer

1 x Miele benchtop deep fryer

1 x BOSH Induction plate 80 cm cooktop (2022)

1 x Miele Hamachi Grill (2017)

1 x Miele oven, touchscreen smart bake (March 2014)

1 x Hoshizaki ice-maker

1 x Miele steam oven

1 x Miele microwave

1 x Dish warmer (2017)

1 x Miele dishwasher (2017)

1 x Sink trash compactor (2017)

2 x Nespresso coffee makers (2017)

1 x Euro wave Wine fridge

1 x Sony stereo (2017)

Upper Pantry:

1 x Liebrerr refrigerator

1 x Hoshizaki ice maker

1 x Miele SC plus dishwasher

Laundry:

2 x Miele dryers (March 2014)

2 x Miele washing machines (March 2014)

1 x Miele rolling ironing board

1 x Rowenta silent steamer

Crew Mess:

1 x Miele fridge/freezer

1 x Bosch dishwasher

1 x Microwave

1 x Nespresso coffee machine

1 x Toaster

1 x 37” LCD TV/SKY/Apple TV

1 x 20” LCD screen security system

• Most crockery and cutlery are from the brands Ethernum, Sambonet, Roberto Cavalli, Rosenthal, Villery Bosch and Murano Cobalto. The glassware is from Schott Zwiesel.

COMMUNICATIONS & NAVIGATION EQUIPMENT

Communications:

1 x Furuno NX-500 Navtex receiver

1 x Thrane & Thranc Mini M

1 x Thranc & Thrane Sat C Transceiver

1 x Fixed Skanti DSC VHF-1000

1 x Fixed Skanti VHF

1 x Simrad GMDSS VHF

1 x Jotron GMDSS VHF (2019)

2 x Icom M-87 Portable VHF

1 x Furuno FA-100 AIS

1 x  SART11

1 x EPIRB

1 X GSM line

2 X VSAT lines

1 X Internal modem/phone line

1 x WIFI modem system Vitriko with 7 repeaters throughout (2020)

Navigation:

1 x Furuno radar 10kw with Simrad software

1 x Furuno radar 4kw

1 x Furuno GP-90 GPS

1 x Simrad GPS chart plotter

1 x Simrad AP50 autopilot

1 x Simrad AR78 gyro repeater

1 x Furuno c-map GPS chart plotter

1 x Navitron Watch Alarm NT991 BNWAS (2017)

 SAFETY & MONITORING EQUIPMENT:

Life Rafts & Buoys:

2 x Zodiac 20 person life rafts

4 x Life buoys, two with orange smoke flares

Fire fighting system:

1 x AFP-200 notifies main fire panel

1 x CO2 sprinkler system for engine room

Numerous CO2 and/or Power and/or foam portable fire extinguishers located

throughout the vessel

Smoke and heat detectors throughout the vessel

Exhaust shutoff valves in galley and engine room

CCTV:

2 x 17’ Monitoring screens

1 x 14’ monitoring screen (captains cabin)

1 x Camera control panel

3 x Motorized cameras with zoom and record

3 x Fixed cameras in engine room, control room and garage

1 x Fixed wide shot camera with semi night vision on Aft

1 x FLIR camera mounted on the mast

TENDER & TOYS

Tender:

1 x Castoldi 16’ jet tender 2016 (Diesel)

Toys:

1 x Seadoo RXP-RS 260

1 x Seabob FS5 (2017)

1 x Seabob FS5 (2019)

3 x Standup paddle board

1 x Zappata racing flyboard

1 x Zappata racing hoverboard

1 x Custom made aquaglide slide

4 x dive kits

1 x Aquaglide pool

1 x Aquaglide pad

1 x Jobe donut

4 x Wakeboards

2 x Childs skis

1 x Adult skis

1 x Glide wing

Masks, snorkels, wetsuits, ski jackets and fins
