1987 Heesen LIONSHARE

• Make: Heesen

• Condition: Used

• Category: Power

• Construction: Aluminum

• Boat Hull ID: 711552

• Has Hull ID: Yes

• Length: 39.62 m / 130 ft

• Length Overall: 39.62 m / 130 ft

• Beam: 25 ft ft

• Make: Caterpillar

• Model: C32

• Fuel: diesel

• Engine Power: 1800|horsepower

• Type: Inboard

• Engine Hours: 2751

• Model: C32

• Engine Power: 1800|horsepower

• Engine Hours: 2751

• Total Engine Power: 3600|horsepower

• Fuel Tanks: 7

• Fuel Tank Capacity: 11597|gallon

• Water Tanks: 3

• Water Tank Capacity: 2000|gallon

• Holding Tank Count: 1

• Holding Tank Capacity: 1135|gallon

2022 REFIT

• New carpets throughout
• New wooden flooring
• New furniture
• Modern interior color scheme
• Replacing deck headliners in the interior
• Bridge equipment upgrades
• New Smart TV’s throughout the vessel
• New blinds
• New mirrors
• New A/C installation throughout vessel

LIONSHARE 103' Heesen 1987/2022 SPECS

Length Overall: 130’

Length at Waterline: 101’9”

Beam: 25’

Draft Minimum: 6’11”

Draft Maximum: 7’7”

Gross Tonnage: 236 GT

Capacities

Fuel Capacity: 11,597 US Gallons | 43,900 liters - 7 fuel tanks

Water Capacity: 2,000 US Gallons | 7,570 liters – 3 water tanks

Gray Water: 1,135 US Gallons | 4,296 liters

Lube Oil Speeds: 211 US Gallons | 801 liters

Cruising

20 knots, max

200 Gallons/hr

RPM 2300

100% Load

12knots, cruise

74Gallons/hr

RPM 1600

38% Load

10 knots, economical

25 Gallons/hr

RPM 1150

20-25% Load

Main Engines

x2 CAT C32 Acert/1800 hp (installed 2012)

Engines rebuilt in June 2020 by Pantropic Power. Gearboxes: ZF3055

Propellers: X2 4-blade props Generators & Electricity

• Port: 11,908, SMOH 2,751 (August 2023)
• Stbd: 11,895, SMOH 2,751 (August 2023)

Generators

X2 65 kW Zenoro

Gens hours:

• Port: 12,400 (Sept 2023)
• Stb: 13,800  (Sept 2023)

X2 John Deere, both new in 2017

Generator top-end service in September 2021 by NPS Diesel

Generator Fuel Consumption: 30 US Gallons/day/per generator/at anchor

Shore Power

X2  ASEA Model AC30-1

In: 180-520 VAC

50-60 Hz

Out: 208/120 VAC

3-phase 60 Hz

Batteries

Main engine starting: X2 Caterpillar (replaced August 2020)

Generator starting: X2 12V Odyssey (new August 2020)

Electronics: Bridge replaced December 2019

Air-Conditioning

Type: Frigomar; 21 tons, 3-chiller unit

210,000 BTU's/hr

Installed in May 2022

Other Machinery

Watermakers: X2 Custom watermakers; 120 US Gallons/hr; 2,800 US Gallons/day (combined)

Stabilizers: Naiad, 12 square foot fins, underway only

Bow Thruster: Hydromar, hydraulic

Steering System: Sperry Marine, hydraulic

Backup Emergency Steering: Cable system, located in the lazzarete

Fuel Filtration – Westfalia

X2 Racor filters on each engine

X1 Racor filter on each generator

Sewage System: Headhunter Type 2; ABS approved August 2017

Freshwater System: X2 Headhunter Mach 5

Communication Systems

Loudhailer: Furuno LH5000

Cellular: Pepwave Max Router

VHF: X2 25W VHF

Navigation Systems

AIS: Class A AIS Transponder

Depth Sounder: Furuno SS260 50/200 Hz

Aimar DST810 NMEA200 Smart Multisen

Automatic Pilot: Raytheon Anschultz Pitostar NX

GMDSS: Navtex NX700P with a printer

Furuno Inmarsat-C FELCOM18

Ship's screens: X4 touch screen displays

Chartplotter: Navnet TZ Touch2 BlackBox

Satcompass: SC70

Wind: Furuno F170

Rudder Indicator: Raytheon

Ship’s Software: Timezero & TRANSAS

Ship’s Computer Nobeltec with Timezero

BNWAS: Furno BR-500 (bridge, crew mess and Captain’s cabin)

Entertainment Systems

X1 65" LG Smart TV – Main Salon

X1 55" LG Smart TV (3) – Sky Lounge

X3 37" LG – Master, Port Aft Cabin, Fwd VIP Cabin)

X1 32" Samsung – Aft Guest Cabin

X1 23" LG – Sarboard Guest Cabin

X1 JVC – Crew Mess

Apple TV – Main Salon, Sky Lounge, Guest Cabin

Playstation 4

Plex Media Server

Galley & Laundry Equipment

Cooking Equipment

X1 Miele 24" Combo-Steam Oven (2022)

X1 Miele 24" Speed Oven- Vitroline (2022)

X3 Garland 2-burner Induction Cooktop

X1 Induction griddle

Refrigeration & Freezer

X1 TRUE Refrigerator

X1 TRUE Freezer (Lazz)

Wine Fridge: X1 Wine Fridge (bridge deck aft)

Beverage Fridge:

X1 Fridge (main aft deck)

X1 Edgestar (main deck aft)

Ice Maker: X1 Scotsman ice maker, commercial (Lazz)

Crew Mess Galley

Frigidaire Side-by-Side Refrigerator with Freezer Drawer; built-in ice/water dispenser

Lambar dishwasher

Black & Decker microwave

Laundry Equipment

X2 Miele washing machines

X2 Miele dryers

X1 set of above washers and dryers (2021)

Deck Equipment

X2 Anchor Windlass: Lofrans, horizontal gear box

X2 Anchors: Pool HCG Lieden; 350 pounds each

X2 Anchor Chains: 5/8" stud link galvanized chain; 500 feet each

Aft Warping Capstans: X1 Lofrans; X1 Quick

Bow Davit: UMT; 1200 pounds

Passerelle: Besenzoni

Deck shower: Yes, swim platform

Safety & Fire Equipment

Ship's safe: Master Stateroom, VIP Stateroom, and Captain's Cabin

Life Rafts: X2 Duarry 16-capacity, X2 KHA 8-capacity

Life Rings: X6 Total; X4 on bridge, X2 on main deck

EPIRB: X1 ACR

Fire-Fighting Equipment

Fire System: Fixed CO2 for engine room only

Fire Hydrants: Bridge deck and 2 on main deck

Fire pumps: FLOMAX 5 and FLOMAX8

Tenders & Toys

32' Intrepid with cabin; (2) x 350hp Mercury engines

X1 2022 SeaDoo Spark Trix 3UP

X1 2020 SeaDoo Spark Trix 3UP

X1 SeaBob

X1 Bauer Dive Compressor

Nautiboy platform

Outdoor cinema with screen

Flyboard, jet skis, wakeboard

Various snorkel and dive gear

Various inflatables

EXCLUSIONS

The name LIONSHARE does not convey.

All the owner's and crew's personal items.

A detailed list of exclusions will be provided at time of sale, upon request
